Weather Stations
Accurate weather data is key to making good irrigation decisions. High Yield Ag offers a digital Ag weather station to that end. Our station features no moving parts for reliable and repeatable performance.
Product Profiles
WSD-100 Premium Ultrasonic Weather Station
Our exclusive weather monitoring system. With no moving parts and no bigger than a 16oz coffee mug, this robust little station packs an entire premium suite of sensors. The WSD-100 incorporates the Agility® Sensor Radio to bring the weather observations back to the MyFarm servers where supplemental calculations are performed for ET, dew point/frost point and wet bulb. The MyFarm web app displays current observations and calculates daily observations needed for irrigation management decisions.
Includes:
- Rain/Snow Detector (Radar)
- Barometric Pressure, Temperature and Relative Humidity
- Ultrasonic Wind Speed and Direction
- Solar Irradiance
Specifications
| Measurement | Range | Accuracy | Resolution |
|---|---|---|---|
| Wind Speed | 0-40 meters/sec | +/- 5% | 0.1 meters/sec |
| Wind Direction | 0-359° | +/- 3° | 1° |
| Temperature | -40 to +80 °C | +/- 0.5 °C | 0.1 °C |
| Humidity | 0-100% | +/- 5% | 1% |
| Pressure | 150-1100 hPa | +/- 1 hPa | 0.1 hPa |
| Precipitation | 0-100 millimeters/hr | +/- 10% | 0.01 millimeters |
| Solar Radiation | 0-2000 W/m2 | +/- 5% | 0.1 W/m2 |
